FREAMS
|
|
FREAMS |
|
| Technology |
LIGHT & TOUGH
Commitment to thorough
weight reduction in details
such as body, spool, and handle.
LT is the new standard for
Daiwa compact spinning, which
was created by evolving the gear
that is the heart of the reel
and the material of the body
that surrounds it to
a tougher one. |
MAGSEALED
Magsealed is the idea of
"blocking liquid with liquid".
It is a wall of mug oil that can
exist semi-permanently due
to magnetism, and is DAIWA's
only one technology that
prevents seawater and dust
from entering the inside
of the reel. This epoch-making
technology announced in 2010
has continued to evolve from
being mounted on line rollers
and mounted on ball bearings
since its announcement, and
is now an indispensable technology
for DAIWA reels and anglers. |
TOUGH DIGIGEAR
Uses "Tough Digi Gear" that
keeps smooth rotation for
a long time. Achieves infinite
noiseless rotation and accurately
responds to the delicate feeling
of the angler's fingertips. |
|
|
|
ATD
It follows the pull of the fish
and controls the drag force and
does not give the fish the initiative.
A loose drag setting is effective
to take advantage of its
characteristics. This setting,
which works strongly when hooking
but can always drag against
pulling fish, brings even large fish
to landing without unnecessarily
rampaging. |
AIR ROTOR
Equipped with an ultra-lightweight
ZAION V air rotor. Achieves light
rotation of unwinding and high
rigidity.
(Achieved about 25% lighter weight
than the previous model) |
LC-ABS (Long cast-ABS)
While keeping the idea of
reducing the contact
resistance of ABSⅡ,
a smoother line emission
is realized by pushing
the contacts forward.
The effect of the ring part
protruding forward makes
it difficult for the line to get
on the ring, improving the
flight distance by about 5%
and trouble-free compared
to the conventional ABS II.
It is a next-generation ABS spool
that truly realizes
LC (= LONG CAST). |
|
|
|
Perfect line stopper
A new shape line stopper that
supports both fine threads
such as PE line and thick
threads such as leaders.
The horizontally long setting
structure saves space
in the vertical direction
and contributes to weight
reduction of the spool. |
For large model hands,
set the handle knob according
to the fishing type
4000 ⇒ Power light M type
(Recommended for sea bass,
light shore jigging, SLJ, etc.)
5000, 6000 ⇒ Power light L type
(Recommended for light shore
jigging, surf casting, etc.)
|
Body with ON / OFF stopper
21FREAMS adopts a body
with a stopper. There is still
a strong desire for a stopper,
and this model uses a stopper
to increase versatility. |
|
|
|
|
| Lineup |
| Finesse Custom |
FC LT1000S
[Target fish] Eging ,
Mebaring
Area trout, etc. |
FC LT2000S
[Target fish] Eging ,
Mebaring
Area trout, etc. |
FC LT2000S-XH
[Target fish] Light salt,
Native Trout,
|
|
|
|
|
|
|
| Original model |
LT2500
[Target fish]
Eging
Versatile |
LT2500-XH
[Target fish]
Eging
Bass fishing
Versatile |
LT3000-C
[Target fish]
Versatile |
LT3000-CXH
[Target fish]
Versatile |
|
|
|
|
LT3000
[Target fish]
Sea Bass
Super light jigging
Versatile |
LT3000-XH
[Target fish]
Sea Bass
Super light jigging
Versatile |
LT4000-C
[Target fish]
Sea Bass
Super light jigging
Cherry salmon |
LT4000-CXH
[Target fish]
Sea bass
Light shore jigging
Super light jigging |
|
|
|
|
LT5000-CXH
[Target fish]
Light shore jigging
Shore casting |
LT6000D-H
[Target fish]
Shore jigging
Shore casting |
|
|
|
|
|
|
|
| Specification table |
| Finesse Custom |
Item
name |
Gear
ratio |
Handle 1
rotation
(cm) |
Weight
(g) |
Max
drag
(kg) |
Line capacity
Nylon Line (lb-m)
PE Line(PE-m) |
Bearing |
Price
[JPY] |
Product
Code |
Parts
Scheme |
| BB |
roller |
| FC LT1000S |
5.2 |
64 |
180 |
5.0 |
2lb-120m
2.5lb-100m
3lb-70m
PE 0.2-210m
PE 0.3-200m
PE 0.4-130m
|
5/1 |
JPY 12,909 |
00060260 |
 |
| FC LT2000S |
5.2 |
68 |
185 |
5.0 |
2.5lb-1200m
3lb-150m
4lb-100m
PE 0.4-200m
PE 0.5-170m
PE 0.6-150m
|
5/1 |
JPY 12,909 |
00060261 |
|
| FC LT2000S-XH |
6.2 |
81 |
185 |
5.0 |
2.5lb-200m
3lb-150m
4lb-100m
PE 0.4-200m
PE 0.5-170m
PE 0.6-150m
|
5/1 |
JPY 12,909 |
00060262 |
|
| Original model |
Item
name |
Gear
ratio |
Handle 1
rotation
(cm) |
Weight
(g) |
Max
drag
(kg) |
Line capacity
Nylon Line (lb-m)
PE Line(PE-m) |
Bearing |
Price
[JPY] |
Product
Code |
Parts
Scheme |
| BB |
roller |
| LT2500 |
5.3 |
75 |
200 |
10.0 |
4lb-230m
6lb-150m
8lb-100m
PE 0.6-290m
PE 0.8-200m
PE 1.0-190m
|
5/1 |
JPY 13,701 |
00060265 |
|
| LT2500-XH |
6.2 |
87 |
200 |
10.0 |
4lb-230m
6lb-150m
8lb-100m
PE 0.6-290m
PE 0.8-200m
PE 1.0-190m
|
5/1 |
JPY 13,701 |
00060266 |
|
| LT3000-C |
5.3 |
80 |
210 |
10.0 |
8lb-150m
10lb-120m
12lb-100m
PE 1.0-200m
PE 1.2-190m
PE 1.5-170m
|
5/1 |
JPY 14,256 |
00060267 |
|
| LT3000-CXH |
6.2 |
93 |
210 |
10.0 |
8lb-150m
10lb-120m
12lb-100m
PE 1.0-200m
PE 1.2-190m
PE 1.5-170m
|
5/1 |
JPY 14,256 |
00060268 |
|
| LT3000 |
5.2 |
77 |
225 |
10.0 |
8lb-150m
10lb-120m
12lb-100m
PE 1.0-200m
PE 1.2-190m
PE 1.5-170m
|
5/1 |
JPY 15,048 |
00060269 |
|
| LT3000-XH |
6.2 |
93 |
225 |
10.0 |
8lb-150m
10lb-120m
12lb-100m
PE 1.0-200m
PE 1.2-190m
PE 1.5-170m
|
5/1 |
JPY 15,048 |
00060270 |
|
| LT4000-C |
5.2 |
82 |
235 |
12.0 |
10lb-190m
12lb-150m
14lb-130m
PE 1.2-310m
PE 1.5-200m
PE 2.0-170m
|
5/1 |
JPY 15,048 |
00060274 |
|
| LT4000-CXH |
6.2 |
99 |
235 |
12.0 |
10lb-190m
12lb-150m
14lb-130m
PE 1.2-310m
PE 1.5-200m
PE 2.0-170m
|
5/1 |
JPY 15,048 |
00060271 |
|
| LT5000-CXH |
6.2 |
105 |
255 |
12.0 |
10lb-330m
14lb-230m
20lb-150m
PE 1.5-430m
PE 2.0-300m
PE 2.5-260m
|
5/1 |
JPY 15,840 |
00060272 |
|
| LT6000D-H |
5.7 |
101 |
325 |
12.0 |
14lb-310m
20lb-250m
30lb-150m
PE 2.5-420m
PE 3.0-300m
PE 4.0-220m
|
5/1 |
JPY 16,236 |
00060273 |
|
|
|
|
